Unmanned Live Broadcast Machine Hardware Streaming Device

Device model: XSWUVCR-50M1CH
USB disk requirements: exfat format, single drive letter
Network video input protocol: HTTP/RTSP/RTMP/RTP/UDP-TS
Network video output protocol: HTTP-FLV/RTSP/RTMP/UDP-TS/HLS/WS-FLV/WS-RAW/ONVIF
Input video encoding format: H.264/H.265
Input audio encoding format: AAC/G.711
Output video encoding format: MJPEG UVC
Output audio encoding format: PCM UAC
Maximum number of network video channels: 1
Maximum total bit rate: 50Mbit (depending on different protocols and encoding formats)
Recording: Support recording to USB disk
Remote upgrade: Support
Remote management: Support remote modification of device parameters and remote playback of device recordings
Product size: 270x216x45mm / 270x216x44
Product weight: 1051g / 1314.5g
Power supply: DC-12V
Working temperature: 0～70 degrees

Questions & Answers
1. Is it a 1U standard chassis? -- No
2. Can the unmanned live broadcast of the device be detected? -- The device can support a series of functions such as superimposing camera images, supporting external 3.5mm audio, and supporting dynamic frame loss. These functions can have a certain anti-detection effect. However, it also has a lot to do with the content of the live broadcast material. Repeated video content or no one appears in the screen, or a large amount of low-quality video content, copying other people's live videos, etc. may also cause risk control. Therefore, we recommend that you must use high-quality and as many video materials as possible to avoid risks
3. Common troubleshooting of UVC stream pushers -- http://docs.xvipcloud.com/web/#/p/4392f655c671c45f7bfd656e415ca51a
4. Do you have to use a computer? Can it be achieved with a mobile phone? -- You must use a computer, both desktop and laptop are fine
5. Can automatic reply be achieved? -- Currently, Taobao and Kuaishou can be paired with our automatic reply software to achieve automatic reply. In addition, the external audio model can support 3.5mm audio real-time interaction
6. Is there interaction in the live broadcast room? -- Currently, Taobao and Kuaishou can be paired with our automatic reply software to achieve automatic reply. Other platforms can only interact manually
7. Can the computer do other things during the live broadcast? -- Yes, it will not affect
8. The USB flash drive cannot be recognized? -- Check whether the USB flash drive is in exFAT format. Connect the USB flash drive to the computer, then right-click the properties to view the SD card format. If it is not in exFAT format, you can format it and select exFAT format
9. Can only one video file be placed in the USB flash drive? -- Support multiple videos to be randomly rotated or sequentially rotated, and it needs to be MP4 format video
10. How long can the video be stored? -- The default USB flash drive is 64G, and you can also use a USB flash drive with larger capacity
11. Can the video be looped? -- Support single video loop and multiple video loops. The loop method can be set to rotate in sequence or randomly
12. Can it support audio real-person intervention? -- Support external 3.5mm audio
13. Does it support multi-account and multi-platform playback? What platforms are supported specifically? -- We have tested Douyin, Kuaishou, and Bilibili and there are no problems with this model. It supports multiple platforms and can play on 3 platforms at the same time without limiting accounts.
14. After connecting to 3.5MM external audio, won’t the sound of the video itself and the 3.5mm external audio be repeated? -- If you connect to 3.5mm external audio, the sound of the video itself will be 80% lower, mainly the sound of the external audio.
15. About violations -- Regarding video materials, you need to prepare them yourself. Our suggestion is to make more non-repeating videos, such as 2 hours of video, 12, 24 hours of loop. Of course, the more videos, the better, and it is recommended to use high-quality videos, not other people’s live screen recordings or repeated videos
16. Can you search for network cameras in the local area network? -- Yes
17. What is the function of the superimposed camera? If the camera screen is superimposed, won’t the material video be blocked? -- The superimposed camera images are intended to deceive the platform's detection. The background can adjust the transparency of the camera images so that people watching the live broadcast cannot see the superimposed camera images.
18. What is included in the delivery? -- The equipment includes accessories: double-headed USB cable, USB flash drive (default 64G), 1 meter network cable. If you buy a device with a webcam, it will come with a camera and camera power supply.
19. Can the video account be broadcast? Can it tell time? -- It can be broadcast, but not tell time.
