Video Capture Device Picture & Camera Freezes

Features：

• Audio and video input interface, HDMI display, supports multiple protocols.

• H.264/H.265 supports remote control, accepts customization

• 10/100/1000M Ethernet adaptive,

• compatible with Hikvision, Dahua and other brands, infrared remote control freeze

Specification：

• Device model: XSWEDR-SLSVIDEO (E21-S)

• Video input: 1 network camera input interface

• Video output: HDMI display display

• Audio input: 1 stereo analog audio input interface

• Network camera resolution: 3840x2160@30fps and below

• Network support: 10/100/1000M Ethernet adaptive, 2.4Gwifi)

• Network video output protocol: SRT/RTSP/RTMP/RTMPS/UDP-TS/HLS/WS-
• FLV/WS-RAW/WEBRTC/GB28181 client/ONVIF/Hikvision protocol

• Output video encoding format: H.264/H.265

• Output audio encoding format: AAC

• Remote upgrade: Support

• Remote management: Support remote modification of device parameters
• platform.xstrive.com registration can be used

• Working power: DC 12V

• Working temperature: -20～75 degrees

• Product size: 150x100x35mm

• Product weight: 325.6g
